| Model | Rated Power | Voltage / Frequency | AirVolume | RPM | Blades | Blade Diameter | Weight |
| HSD-7300 | 1.5KW | 110-415V / 50-60Hz | 13800 m3/min = 487342 CFM | 55 | 6 pcs | 7.3M(24') | 140kg |
| HSD-6700 | 1.5KW | 110-415V / 50-60Hz | 13000 m3/min = 459090 CFM | 55 | 6 pcs | 6.7M(21') | 135kg |
| HSD-6100 | 1.5KW | 110-415V / 50-60Hz | 12100 m3/min = 427307 CFM | 75 | 6 pcs | 6.1M(20') | 130kg |
| HSD-5500 | 1.5KW | 110-415V / 50-60Hz | 11200 m3/min = 395524 CFM | 75 | 6 pcs | 5.5M(18') | 125kg |
| HSD-4900 | 1.1KW | 110-415V / 50-60Hz | 10800 m3/min = 381398 CFM | 75 | 6 pcs | 4.9M(16') | 120kg |
| HSD-4500 | 1.1KW | 110-415V / 50-60Hz | 10200 m3/min = 360209 CFM | 75 | 6 pcs | 4.5M(15') | 115kg |
| HSD-4000 | 0.55KW | 110-415V / 50-60Hz | 9800 m3/min = 346083 CFM | 100 | 6 pcs | 4.0M(13') | 110kg |
| HSD-3600 | 0.55KW | 110-415V / 50-60Hz | 8500 m3/min = 300174 CFM | 100 | 6 pcs | 3.6M(12') | 80kg |
| HSD-3000 | 0.55KW | 110-415V / 50-60Hz | 6500 m3/min = 229545 CFM | 100 | 6 pcs | 3.0M(10') | 65kg |
| HSD-2500 | 0.55KW | 110-415V / 50-60Hz | 5000 m3/min = 176573 CFM | 100 | 6 pcs | 2.5M(8') | 60kg |
| HSD-2000 | 0.55KW | 110-415V / 50-60Hz | 4000 m3/min = 141258 CFM | 100 | 6 pcs | 2.0M(6') | 55kg |
NORDL Industrial Ceiling Fan
This professionally designed HVLS industrial ceiling fans is equipped with high-quality Nord decelerator (reducer), providing excellent performance and reliable operation. Whether it is a high and large-sized factory, agricultural greenhouse, logistics warehouse. or commercial space, our industrial large fan can easily handle it, providing a comfortable airflow coverage.
Nord reducer is renowned for its outstanding performance and durability, ensuring smooth and stable operation of the fan. The reducer's superior design reduces kinetic energy loss, effectively saving energy costs, and guaranteeing the fan's long-term operation. The fan's core is equipped with the Nord reducer, driving a large-diameter fan with a high torque, resulting in low noise operation, and maintenance-free, ensuring a quiet and efficient working environment.
Application
Manufacturing Areas
Commercial Spaces
Indoor Sports Arenas
Transportation Hubs
Factory workshops, Production lines, Manufacturer, Warehousing facilities
Large shopping malls, Supermarkets and retail stores, Exhibition centers
Sports stadiums, Swimming pools, Indoor sports facilities
Docks and piers, Airport terminals, Train stations and subway stations
Feature
Material
Drive System
Blade Design
Dust Resistance
Use high-strength, corrosion-resistant metals, to ensure the fan's structural integrity and long-term durability.
Equip with high-efficiency IE3 motors + NORD decelerator
Utilize aerodynamic designs to ensure efficient airflow and reduce noise levels
Employ sealed designs for the motor and internal mechanical components to prevent the impact of dust and moisture on fan operation
Size Information
Parameters
Main Components
1. Germany NORD coaxial bevel wheel decelerator with diameter of axle 40MM.
2. German Original Simrit Double Oil Seal, Design for Output Shaft.
3. Shell Omala S4 lubrication oil, zero maintenance for over 20000 hours.
4. Original SKFVL Enhanced Roller Bearing.
5. IE3 High efficiency motor, 10%-15% energy saving than IE1.
Drive System
1. Multi-Speed Adjustment: Supports multiple fan speed settings to meet different environmental needs.
2. Energy-Efficient: Designed for efficient energy utilization, reducing electricity costs.
3. Easy Installation: Simple and straightforward installation steps to minimize installation complexity.
Control System
1. Simulated Airfoil-Shaped Fan Blades with High-performance aluminum alloy material.
2. Wing-shaped fan blades ensure the fan's effectiveness.
3. Built-in reinforcement, split rib and full rib combination.
Airfoil-Shaped Fan Blades
1. The chassis wheel provides the main support point of the ceiling fan, ensuring the stability and safety of the ceiling fan during operation, unique double Wheel design.
2. Materials used Hardened aluminum alloy + T6 heat treatment + CNC precision machining. 20-year design service life, maintain durability.
3. Chassis wheel dynamic balance is fully inspected to keep the fan running smoothly without jitter.
Double Chassis Wheel
1. Adaptable to various installation environments and structures, such as K/O/C/L, and other types of installation structures.
2. Made from high-strength steel, providing stable support.
3. Easy to install with multiple pre-drilled screw holes provided.
Suspension Structure
We have an experienced engineering team on electricity, machanism and architecture who will provide the most reasonable installation plan for different structures according to stress analysis, and can install fans for qualified structures.
We all know that installation is a very vital process, so during it, strict norms & installation standards and our profession must eliminate all your doubts.
Installation
Application
FAQs
Are your ventilation and cooling systems suitable for large industrial areas?
Yes, our systems are designed to provide efficient airflow and temperature control in large industrial spaces, ensuring a comfortable working environment.
Can your equipment be customized to specific facility requirements?
Absolutely, we offer customization services to tailor our ventilation and cooling solutions to meet the unique needs of your facility.
How energy-efficient are your ventilation and cooling products?
Our products are designed with energy efficiency in mind, utilizing advanced technologies to reduce power consumption while maintaining optimal performance.
Do you provide installation and maintenance services?
Yes, we provide comprehensive installation and maintenance services to ensure your ventilation and cooling systems operate at peak efficiency.
What kind of support can I expect after purchasing your product?
We offer ongoing customer support including operational training, technical assistance, and a warranty for our products.
What types of environments are your ventilation and cooling systems best suited for?
Our systems are versatile and ideal for a range of environments, from manufacturing plants and warehouses to commercial complexes and agricultural facilities. They are designed to adapt to different climatic conditions and space sizes.
Construction Appointment
1
Submission of Project Appointment
2
Send the Drawings
3
Design Scheme
Make a Project appointment by contacting customer service or sending an email to us.
Please send the measured drawings to customer service, and be sure to provide accurate measurements.
We will propose a solution within 3-14 days. Please be patient and wait for our response.
4
Engineering Quotation
5
On-site Construction
6
After-Sales Service
After both parties agree on the proposed solution, we will send the engineering quotation. Please pay attention to check and review it.
Once the equipment is ready, construction team will promptly proceed with the installation and commissioning process.
If you encounter any issues during usage, please consult our online customer service for assistance.
Send us a message
Get Your Custom Solution Today!
Our dedicated team of engineers specializes in providing tailored ventilation and cooling solutions that cater to your unique needs. With cutting-edge technology and a commitment to sustainability, we ensure your spaces stay cool, energy-efficient, and comfortable.
Connect with us for a personalized consultation and discover how we can transform your environment. Our attention to detail and customer-centric approach guarantee a seamless experience from design to installation.
Don't let challenges slow you down. Send us a message now, and let's create the ideal solution for your space!
At HENGSHUANGDA®, we provide more than just cooling and ventilation products, we deliver tailored environments for both indoor and outdoor spaces. Our proficiency is in developing customized solutions that cater to your distinct needs, encompassing a wide range of products from individual units to complete ventilation systems. Our engineering team blends advanced technology with innovative designs to create efficient, reliable solutions.
Whether you need a specialized cooling unit for a unique indoor area or ventilation system for outdoor use, our comprehensive services include consultation, design, installation, and maintenance. Trust us to maintain the perfect temperature and air quality in your spaces.
For a clear vision of your custom project, our 3D rendering services bring your prospective solution to life before installation. Rely on us for a thorough consultation, precise design, and meticulous maintenance services. With HENGSHUANGDA®, experience a new dimension in indoor cooling and ventilation solutions.
Products
Contact Us
- PHONE: +86 191 2421 8180
- FAX: +020 3999 0969
- WHATSAPP: +86 191 2421 8180
- WECHAT: +86 191 2421 8180
- EMAIL: info@hengshuangda.com
- LOCATION: GUANGZHOU, CHINA
- Copyright © 2024 HENGDA. All rights reserved.
Large and High Space Installation Case
Install a 7.3m diameter NORDL series industrial ceiling fan in a tall and large factory building with a steel structure.
Large and High Space Installation Case
Large industrial ceiling fans are used in tall and large spaces to create internal air circulation.
Flat-Floor Factory Installation Case
Ceiling fans can also be installed in flat-floor factory workshops with a height of 5-7m to increase air circulation.
Warehouse Installation Case
Install ceiling fans to provide airflow in tight spaces within the warehouse.
